iqTool
The iqTool GUI is dedicated to the manual management of iqInterface device.
You can use it to perform the following actions:
- You can configure the connection between iqInterface and Windows PC
- Standard IO-Link actions in IO-Link master mode
- Make a simulation of an IO-Link device in generic device mode
- Monitor IO-Link communication status in master mode and device mode
- Observe the communication activity with detailed description in the log text box on the right side
The new iqToolPro is available as a pre-release
The new iqToolPro is available as a pre-release. It brings visualization, configuration and validation of IO-Link devices together in one tool.
- Built-in IODD interpreter // Reads IODD files directly
- Data Storage // Show, read and write
- Process data & parameters // Visualized with IODD names
- SMI visualization // Standardized Master Interface
- Parameter read / write // In different formats
- Device validation // Quick parameter test
iqToolPro in action
- Selected views for configuration, validation and visualization
- Built-in IODD interpreter // Parameters named and decoded from the IODD.
- Device validation // Read, write and out-of-range tests; values restored afterwards.
- Visualization // Process data and parameters over a selectable time window.
